Mean line between curves

Published: 19 April 2016

If you suddenly do not know, then the plug-in has a community in the VK. And today in discussions there I was asked to make a new function that builds an average line between two polylines.
The function was not difficult, so I left it for writing one evening =) Although, I did not think over all the nuances that may arise in its work - this task I assign to users!

Meet – collection of functions for working with polylines (from version 1.1.0.0) added one more feature "Construction of the middle line". The middle line is built between the two specified curves, which means between segments, polylines and splines. Naturally, these pairs do not have to be equal.

mpPl-MiddleLineNaturally, my version is different from the existing analogs! Namely - in my version, the constructed middle line can be immediately simplified! Those. remove from the polyline points that lie on the same line (this function is also separate). In general - fewer words! Upgrade and try!

P.S. I apologize that there is still no certificate. I do not like to do them, and the free time is not enough now

Comments

AutoCad 2017

Published: 23 March 2016

autocad-2017-lockup-1200x132

Added support for AutoCAD 2017

Comments

700 user

Published: 07 March 2016

700-11-600x370

Congratulations to the user Василий Лосев (login losvas)! He became the 700th user registered on the site and receives a constant 50% discount on all purchases!

Comments

Scaling of Formats

Published: 27 February 2016

When I got into the design institute many years ago, my acquaintance with AutoCAD happened. But the trouble is that there were no teachers according to the program and it was necessary to master yourself, absorbing the experience and experience of colleagues. And colleagues, in most cases, were "aunts" - I think many people know the application of this word to the design sphere ))

So - in those days, everyone used AutoCAD, as they say, as a "Cullman in the TV." Which is not surprising - many in fact before that years and worked on the Cullman. As I recall the callouts made by segments and text - he already throws a shiver. About the notes, also performed in single-line text, generally keep quiet! Naturally, I also had to work on the scheme "Cullman in the TV." Many people know this scheme - everything is done in the model, everything is drawn as it should turn out on paper. And if you need to draw a plan in the 50th scale, then take a calculator in hand and draw, multiplying everything by 2...

Comments

Set up your own base of products!

Published: 21 February 2016

EditBaseInsertion

A very interesting question was asked at the forum - "can I "disable" bases that I do not need?". Of course, it's about function Product Insert.

Thinking a bit, I came to the next:
1. The realization of this possibility is not as complicated as it seems
2. I have not seen anything like this in other products

As a result, the function Product Insert (version 2.0.1.0) has the ability to edit the list of documents used by the function.

I did not stuff this window with various "chips", such as searching for documents or grouping them into sections - all the documents go in a solid list. I think, the opportunity will not be so widely in demand, so it did not waste energy on it. Who needs to disable some documents - he will cope with this and having an ordinary list =)
