The Tools plugin is a collection of small commands that fall short of the level of full-fledged plugins. Something like small scripts. And today we are pleased to introduce you two new commands:

Grid bubbles visibility

Batch enable/disable bubbles of the selected grids or grids on the current view.

Select annotations

A small command that allows you to select only certain annotations by the frame: dimensions, tags and text.

And also in this update we added the ability to hide/show reinforcement in the current view. Corresponding buttons in the dropdown lists:

Submit your ideas for small and useful command, and we will definitely consider all your suggestions!

Enjoy your work with ModPlus!

An interesting idea was suggested to us on the forum - to set layers for blocks by their name. We thought and decided that it really can be convenient and can significantly speed up the work. Especially if you have to work with a large number of blocks.

Therefore, we have added such an opportunity! Meet - Auto Layers 2.0.

We have completely redesigned the plugin interface and refactoring the code. We added the setting of layers for blocks to the standard functionality and added a new functionality for setting layers for blocks by name. Now you can set one layer for all blocks or a specific layer for blocks with specific names.

Everything should be quite simple and straightforward, but we made a small video anyway:

Give it a try, leave feedback and write your ideas. Sooner or later, but we try to implement all the wishes of our users!

Enjoy your work with ModPlus!

Dear users, congratulate ModPlus! Now ModPlus is a trademark! And now we can safely write ModPlus™

We were repeatedly asked to make a plugin that would dimensioning the columns on the plan. Initially, we had plans to develop a large and complex plugin for dimensioning, but we decided to postpone this idea. And we added the functionality with the dimensioning of columns to the plugin Internal dimensions on plan.

Since version 2.0, the plugin now has two modes of operation:

The new mode process rectangular columns that are orthogonal to the floor plan:

Some of the dimensions in the screenshots have been moved manually, because after the plugin was running, they got on top of each other, but it's easier to move 2 dimensions than to create 22 manually!

Give it a try, share your ideas and comments. Enjoy your work with ModPlus!

Today we have released the version 2.0 of the Dimensions by line plugin, in which we added a small, but very significant addition - now you can specify a point to place the dimension line!

To demonstrate the new functionality, we made a small video:

Enjoy your work with ModPlus!
